ADJUSTABLE ACROW SPAN
Reliable Support, Adjustable to Every Need
Adjustable Acrow Spans
* Main body of the outer & inner members are made up of 14/12 gauge M.S. sheet
* Bottom of the outer member is made up of 50×6 mm M.S. plate
* Bottom of the inner member is produced using 40x40x6 mm “T” angle
* 10mm Rod Zig Zag Bending.
* 19mm Bolt Nut on Top 1 Nos.
* 1 Coat of Oxford Blue Paint.
1/2 * 65″ X 6″ Flat Top Full Length 4 ”.
| Size Range (Min - Max) | ||
| Type | Minimum Extension (m) | Maximum Extension (m) |
|---|---|---|
| ESO + ESI | 1.75 | 2.70 |
| SO + ESI | 2.40 | 3.45 |
| SO + SI | 2.45 | 4.16 |
| SO + LI | 3.05 | 4.75 |
| LO + SI | 3.15 | 4.85 |
| LO + LI | 3.15 | 5.50 |
Features of Adjustable Acrow Span
High Load Capacity
Engineered to bear heavy loads safely during slab and beam formwork applications.
Adjustable Length Design
Easily adjustable to different lengths, providing flexibility across various construction projects.
Robust Mild Steel Construction
Manufactured from high-quality 14/12 gauge mild steel sheets for superior strength.
At Lakshmi Enterprises Scaffolding, we are committed to providing high-quality scaffolding and shuttering solutions tailored for modern construction needs.
